Fraimlite dimensions

Anyone know, or where to find, the maximum unit depth that can be placed on a Fraimlite shelf?

Thanks.

ATB, J

Fraim Lite According to the brochure (not sure if all the D is usable but over all depth is 442 mm)

Shelf Dimensions

(wooden shelf)

452 x 340mm (W x D)

Thanks,

ATB, J

Updated with overall depth

Be careful also about where the sockets are on the components you wish to use. The central rear pillars have a nasty habit of getting in the way IME.

Indeed, I had to get the ‘narrow’ rear legs to accommodate the cable layout on my NC boxes.

ATB, J

What’s the width of the narrow leg? I’ve twisted the standard leg now to fit my BNC cable on the NDS…

If you search the forum you’ll find both images and dimensions.

NB Standard height only.

ATB, J

390mm from the front of the shelf to the inside face of the rear leg and 340 front to back of the shelf itself. If it’s a top shelf you can push it a bit as long as there’s only one rear foot.

Erm…. mm or cms?

39mm from the front of the shelf to the front face of the rear legs seems very small……

ATB, J

Well spotted.

Apologies for the pedantry :innocent:

ATB, J
